First Class Design for Protection of the Environment
ADSORBENTS
RATE offers proprietary Adsorbents for H2S, CO2, and mercaptan Removal through OEM manufacturing with performance guarantees.
One of the RATE technologies is related to SO2 removal from the tail gas incineration as SETR technology. The SO2 is recovered and it is recycled back to the SRU. The adsorbent for this technology is SETR ADS700. RATE license the technology and supply the Adsorbent.
There are other adsorbents available as regenerable and nonregenerable for H2S removal when the conventional Claus technologies are not economical.
Adsorbents
- Activated Alumina
- Activated Carbon
- Activated Clay
- Molecular Sieves
- Alumino-silicate Adsorbents
- ADS Metal Oxide Based Products
Non-regenerative Sulphur Adsorbents
The following table represents non-regenerative adsorbents
| Adsorbent | Type | Applications | Shape | Benefits |
|---|---|---|---|---|
| SETR ADS700 | Activated Alimina | H2S and S02 Adsorbent | Spherical | SO2 conversation and H2S adsorbent |
| ADS SS-25 | Iron Hydroxide | H2S removal from wet gas (80% RH) | Extrudate Granule | High H2S capacity Low cost |
| ADS CS-12 | Cu/Zn | H2S/COS/Mercaptans/Arsine/PH3 from both liquid and gas | Table Extrudate | Mild Sulfur capacity Broad sulfur species |
| ADS ZS-60 | Zn/Mn | H2S removal from both liquid and gas | Extrudate | Mild Sulfur capacity |
| ADS T-90/95 | ZnO | H2S removal for High temperature gas | Extrudate | High H2S Capacity |
| ADS NS-75 | Nickle | H2S/COS/Mercaptans C0 and heavy sulfides | Extrudate | Mild Sulfur capacity Broad sulfur species |
| ADS LAS-20 | PbO | COS/Arsine/Sulfur/PH3 | Sphere | Mild Sulfur capacity Broad sulfur species |
| ADS ASR | CuO/AI203 | H2S/COS/Mercaptans/Arsine/PH3 from both liquid and gas | Sphere | Mild Sulfur capacity Low density |
Regenerative Sulphur Adsorbents
The following table represents regenerative adsorbents.
| Adsorbent | Type | Applications | Shape | Benefits |
|---|---|---|---|---|
| ADS SA | Promoted Alumina | COS/H2S/CO2 removal from both liquid and gas | Sphere | Remove to ppb level |
| ADS AX-600 | Alumina/Zeolite | Water, Mercaptans and oxygenates removal | Sphere | Remove broad impurities |
| ADS SD-05/06 | Promoted Alumina | Water, COS/H2S/CO2 removal | Sphere | For Oleflex PDH plant Low cost |
| ADS ACS | Promoted activated carbon | H2S removal | Granule Extrudate | Low cost |
